NP0152G TECO-Westinghouse 15 hp 3600 RPM 254T 230/460V TEFC Severe Duty SGR 3-Ph Motor
NP0152G TECO-Westinghouse 15 hp 3600 RPM 254T 230/460V TEFC Severe Duty SGR 3-Ph Motor
NP0152G TECO-Westinghouse 15 hp 3600 RPM 254T 230/460V TEFC Severe Duty SGR 3-Ph Motor
NP0152G TECO-Westinghouse 15 hp 3600 RPM 254T 230/460V TEFC Severe Duty SGR 3-Ph Motor

TECO WESTINGHOUSE

NP0152G TECO-Westinghouse 15 hp 3600 RPM 254T 230/460V TEFC Severe Duty SGR 3-Ph Motor

(No reviews) Write a Review
$1,340.54
SKU NP0152G
Shipping Calculated at Checkout
Voltage 230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 33.2/16.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
Adding to cart… The item has been added
Description

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

  • 15 hp 3600 RPM, 33.2/16.6 amps 230/460 Volts 60 Hz. Three Phase
  • NEMA 254T Frame, 4 x 1 5/8" Dia. Keyed Shaft
  • Cast Iron Frame, Totally Enclosed Fan Cooled (IP56)
  • Service Factor: 1.15, Thermal Overload Protection: None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • Suitable for Inverter Use per NEMA MG-1 Part 31.4.4.2
  • Inverter Duty Speed Range: 20:1 Variable Torque, 10:1 Constant Torque
  • Motors are U.L. Recognized, CSA Approved and CE Marked
  • 1 Year Manufacture Warranty

For use in electrically risky environments. It uses an SGR bearing protection ring to divert harmful voltages from the bearing.

Specifications
Voltage 230/460V
Horsepower 15 HP
RPM 3600
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 33.2/16.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Severe Duty
!
