TECO WESTINGHOUSE
NP0154 TECO-Westinghouse 15 hp 1800 RPM 254T 230/460V TEFC Severe Duty 3-Ph Motor
(No reviews)
Write a Review
Write a Review
TECO WESTINGHOUSE
NP0154 TECO-Westinghouse 15 hp 1800 RPM 254T 230/460V TEFC Severe Duty 3-Ph Motor
$1,150.00
$849.95
SKU
NP0154
Shipping
Calculated at Checkout
Voltage
230/460V
Horsepower
15 HP
RPM
1800
Phase
Three Phase
Frame
254T
Enclosure
TEFC
Hertz
60 Hz
Amperage
34.5/17.3 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
Duty
Severe Duty
NP0154 TECO-Westinghouse 15 hp 1800 RPM 254T 230/460V TEFC Severe Duty 3-Ph Motor
The NP0154 is a TECO-Westinghouse NEMA Premium electric motor designed for severe duty industrial applications. It serves as a reliable replacement motor offering high efficiency and robust performance in demanding environments.
Key Specifications
- Horsepower: 15 hp
- RPM: 1800
- Voltage: 230/460 V
- Amperage: 34.5/17.3 A
- Enclosure: Totally Enclosed Fan Cooled (TEFC), IP56
- Frame / Diameter: NEMA 254T, Cast Iron Frame
- Shaft Dimensions: 4 x 1 5/8" Diameter, Keyed Shaft
- Rotation: Reversible
- Bearings: Ball Bearings
Product Features & Fitment
This motor features a rigid base for secure mounting and is suitable for inverter duty use, complying with NEMA MG-1 Part 31.4.4.2 standards. It supports a wide inverter duty speed range of 20:1 for variable torque and 10:1 for constant torque applications. The motor is equipped with Class F insulation and does not include thermal overload protection.
Warranty
1 Year Manufacturer Warranty
1 Year Manufacturer Warranty
| Voltage | 230/460V |
|---|---|
| Horsepower | 15 HP |
| RPM | 1800 |
| Phase | Three Phase |
| Frame | 254T |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 34.5/17.3 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
| Duty | Severe Duty |
