NP0204 TECO Westinghouse 20 hp 1800 RPM 256T Frame 230/460V TEFC 3-Phase Motor

NP0204 TECO Westinghouse 20 hp 1800 RPM 256T Frame 230/460V TEFC 3-Phase Motor

The NP0204 is a robust 20 horsepower, 1800 RPM three-phase motor designed for industrial applications such as fans, blowers, pumps, crushers, compressors, mixers, and conveyors. It is engineered to replace similar NEMA 256T frame motors requiring reliable performance and durability.

Key Specifications

• Horsepower: 20 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 46.0/23.0 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC), IP54
• Frame / Diameter: NEMA 256T
• Shaft Dimensions: Keyed shaft, 1 5/8" diameter x 4" length
• Rotation: Reversible
• Bearings: Ball bearings

Product Features & Fitment

Constructed with a cast iron rigid base, this motor offers enhanced durability and stability during operation. It features Class F insulation and is suitable for inverter duty use, supporting variable torque speed ranges of 20:1 and constant torque ranges of 10:1 in compliance with NEMA MG-1 Part 31.4.4.2. The motor is designed for easy installation and is UL recognized, CSA approved, and CE marked for safety and compliance.

Warranty

1 Year Manufacturer Warranty
