- 1/2 hp 1200 RPM, 6.2/3.8-3.1 amps, 115/208-230 Volts 60 Hz, Permanent Split Capacitor (PSC)
- NEMA 56Z Frame Keyed Shaft 5/8" Diameter x 6"
- Service Factor = 1.0, Thermal Protection = Automatic
- No Base, Reversible, Ball Bearings, Class B insulation
- 1 Year Manufacture Warranty
Condenser Fan Motors are used in air conditioning coolant condenser units usually found outdoors. Shaft may be vertical or horizontal. ODPAO = Open Open Drip Proof Air Over so motor must be in air-stream. 5KCP49PN9812S
