Q0056 TECO-Westinghouse 5 HP 1200 RPM 215T 230/460/796V ODP 3-Phase Oil Well Pump Motor

TECO WESTINGHOUSE, NEMA PREMIUM ELECTRIC MOTOR

• 5 hp 1200 RPM, 14.9/7.45/4.31 amps 230/460/796 Volts 60 Hz. Three Phase
• NEMA 215T Frame, 3 3/8 x 1 3/8" Dia. Keyed Shaft

• Cast Iron Frame, Open Drip Proof

• Service Factor: 1.15, Thermal Overload Protection: None
• Rigid Base, Reversible, Ball Bearings, Class F Insulation
• Rodent Screens, 5% Minimum Slip

• 1 Year Manufacture Warranty


Oil well pump motor for use on oil pumps. Also good for any application requiring NEMA Design D torques.
