U1P1DC Nidec 1 hp 3600 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor

U1P1DC Nidec 1 hp 3600 RPM 56C Frame 208-230/460V TEFC 3-Phase Electric Motor

SKU:
U1P1DC
Weight:
30.00 LBS
Width:
13.00 (in)
Height:
11.00 (in)
Depth:
9.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
208/230/460V
Horsepower:
1 HP
RPM:
3600
Phase:
Three Phase
Frame:
56C
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
2.7/1.4 Amps
Bearings:
Ball Bearings
Service Factor:
1.25
Insulation Class:
Class F
Mounting:
Rigid Base
Was: $471.50
Now: $420.79
Adding to cart… The item has been added
  • 1 hp 3600 RPM,  2.9-2.7/1.4 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.25, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C- Face motor can be used for many applications requiring a three phase electric motor.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. FM69

!
