UJ7P1DFP US Motors 7 1/2 hp 3600 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor
UJ7P1DFP US Motors 7 1/2 hp 3600 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor
UJ7P1DFP US Motors 7 1/2 hp 3600 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor
UJ7P1DFP US Motors 7 1/2 hp 3600 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor

US Motors

UJ7P1DFP US Motors 7 1/2 hp 3600 RPM 3-phase 184JP Frame 208-230/460V Close-Coupled Pump Motor

(No reviews) Write a Review
$1,095.95
$978.54
SKU UJ7P1DFP
Availability Subject to availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 3600
Phase Three Phase
Frame 184JP
Enclosure TEFC
Hertz 60 Hz
Amperage 19.0/9.5 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 7 1/2 HP 3600 RPM, 19.9-19.0/9.5 amps, 208-230/460V 60hz. 3 Phase.
  • NEMA 184JP Cast Aluminum Frame, JP stainless steel shaft
  • 1.15 Service Factor, Auto Overload Thermal Protection, Class F insulation
  • Reversible Rotation, Totally Enclosed Fan Cooled,
  • Rigid Base, Ball Bearings,

Close Coupled motors have the pump impeller mounted directly on the shaft. 1 Year Manufacture Warranty. TEFC = Totally Enclosed Fan Cooled, Proof, FL38

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 1/2 HP
RPM 3600
Phase Three Phase
Frame 184JP
Enclosure TEFC
Hertz 60 Hz
Amperage 19.0/9.5 Amps
Bearings Ball Bearings
Insulation Class Class F
Rotation Reversible
Mounting Rigid Base
!
