X000 Marathon 1/4 hp 115V 1075 RPM (3 speed) OPAO 48Z Frame Blower Motor

X000 Marathon 1/4 hp 115V 1075 RPM (3 speed) OPAO 48Z Frame Blower Motor

This Marathon blower motor is designed for HVAC applications requiring reliable air movement inside buildings. It replaces standard 1/4 hp motors and is suitable for systems needing a 3-speed, 115V motor with a keyed shaft.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 3.4 amps
• Enclosure: Open Open Air Over (OPAO)
• Frame / Diameter: NEMA 48Z Frame
• Shaft Dimensions: Keyed shaft, 1/2" diameter x 4" length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a Permanent Split Capacitor (PSC) design with automatic thermal protection and Class B insulation for durability. It does not include a base and must be mounted in an air stream due to its open enclosure. The reversible shaft orientation allows flexible installation options.

Warranty

1 Year Manufacturer Warranty
