X32P1B Nidec 1 1/2 hp 3600 RPM 143T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

X32P1B Nidec 1 1/2 hp 3600 RPM 143T Frame (Rigid Base) 230/460V TEFC 3-Phase Hazardous Duty Motor

The X32P1B is a general-purpose, hazardous duty motor designed for Division 1 locations, suitable for Class 1 Group D and Class 2 Group FG environments. It replaces standard industrial motors requiring a robust, reliable solution for demanding applications.

Key Specifications

• Horsepower: 1 1/2 hp
• RPM: 3600
• Voltage: 230/460 V
• Amperage: 3.9/1.9 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 143T Cast Iron
• Shaft Dimensions: 7/8" Diameter x 2 1/4" Length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount for secure installation and is constructed with Class F insulation for enhanced thermal protection. It includes a keyed shaft and a wiring diagram located on the motor nameplate to facilitate proper electrical connections. Overload protection is not included.

Warranty

1 Year Manufacturer Warranty
