XP1/56 TECO-Westinghouse 1 1/2 HP 1200 RPM 182T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

XP1/56 TECO-Westinghouse 1 1/2 HP 1200 RPM 182T Frame 230/460V TEFC Cast Iron 3-Ph Exposion Proof Motor

SKU:
XP1/56
Weight:
125.00 LBS
Width:
17.00 (in)
Height:
13.00 (in)
Depth:
16.00 (in)
Shipping:
Calculated at Checkout
Voltage:
230/460V
Horsepower:
1/2 HP
RPM:
1200
Phase:
Three Phase
Frame:
182T
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
5.10/2.55 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Insulation Class:
Class F
Rotation:
Reversible
$649.27
Adding to cart… The item has been added

TECO WESTINGHOUSE NEMA PREMIUM EXPLOSION PROOF MOTOR

  • 1 1/2 hp 1200 RPM, 1-Speed, 5.10/2.55 amps, 230/460 Volts 60 Hz. Three Phase
  • 182T Cast Iron Frame, Shaft: 1 1/8" x 2 3/4" with Key
  • Ball Bearing, Reversible Rotation, Overload Protector: Manual
  • Service Factor = 1.15, Insulation Class F
  • Explosion Proof: Class I Div. 1 Group C and D, Class II Groups E, F, and G.
  • 1 Year Manufacture Warranty

Explosion Proof Motor For Use Where Ever Explosive Gases or Grain Dust May Be Present. Totally Enclosed Fan Cooled (TEFC)

!
