Marathon

Y465 Marathon 1 hp (2 speed) 460V 1800/900 RPM ODP 145T Frame 3-Phase Variable Torque Motor

(No reviews) Write a Review
$762.22
SKU MY465
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
STATUS ON SALE
Voltage 460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 145T
Enclosure ODP
Hertz 60 Hz
Amperage 0.75 Amps
Bearings Ball Bearings
Speeds 2-Speed
Insulation Class Class B
Rotation Reversible
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1 hp 1800/900 RPM, 1.5, 0.75 amps, 460 Volts 60 Hz, 3-Phase, 2 Winding
  • NEMA 145T Frame, Shaft 2 1/4" x 7/8" Diameter, 2 speed
  • Service Factor = 1.15, Thermal Protection = None
  • Rigid Base, Reversible rotation, Ball Bearings, Class B insulation
  • 1 Year Manufacture Warranty

For use on blowers and pumps having variable running loads. Shaft should be horizontal. ODP = Open Drip Proof. 145TTDR5701

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
STATUS ON SALE
Voltage 460V
Horsepower 1 HP
RPM 1800
Phase Three Phase
Frame 145T
Enclosure ODP
Hertz 60 Hz
Amperage 0.75 Amps
Bearings Ball Bearings
Speeds 2-Speed
Insulation Class Class B
Rotation Reversible
Mounting Rigid Base
!
