YC1P2B Nidec 1 hp 1800 RPM 143T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

YC1P2B Nidec 1 hp 1800 RPM 143T Frame (Rigid Base) 230/460V TEFC 3-Phase Div 1 Hazardous Duty Motor

SKU:
YC1P2B
Weight:
80.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $913.00
Now: $815.50
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 3.0/1.5 amps  230/460 Volts 60 Hz Three Phase Motor
  • NEMA 143T Cast Iron frame Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose, Corrosion resistant, Division 1 hazardous location motor for class 1 group D.  Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. CP11

!
