Y601 Marathon 1/3 hp 1800 RPM 3-Phase 56C Frame TENV (rigid base) 230/460V Marathon Motor

Y601 Marathon 1/3 hp 1800 RPM 3-Phase 56C Frame TENV (rigid base) 230/460V Marathon Motor

This Marathon 1/3 horsepower, 3-phase electric motor is designed for industrial applications requiring reliable, constant torque performance. It features a totally enclosed non-ventilated (TENV) design and a rigid base, making it suitable for pump or gear head mounting.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 1.2/0.6 A
• Enclosure: Totally Enclosed Non-Ventilated (TENV)
• Frame / Diameter: NEMA 56C frame
• Shaft Dimensions: 5/8" diameter x 1 7/8" length, keyed shaft
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor includes a C-face mount with four threaded bolt holes spaced 5 7/8" on center across the shaft, allowing easy attachment of pumps or gear heads. It is inverter (vector) duty rated with 1000:1 constant torque and comes with a wiring diagram on the nameplate for straightforward installation. The rigid base design ensures stable mounting in various industrial setups.

Warranty

1 Year Manufacturer Warranty
