3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor
3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor
3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor
3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor
3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor
3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor

Nidec

3252 Nidec | 1/6 hp 1725 RPM 1-Speed 115V, 48N Oil Burner Motor

(No reviews) Write a Review
$197.80
$177.09
SKU 3252
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/6 HP
RPM 1725
Frame 48N
Amperage 3.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Flange
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/6 hp 1725 RPM 1-Speed 115V; 3.1 amps
  • Shaft 1/2" x 2.0"
  • Rotation: Reversible
  • Frame 48N
  • 5.6" Diameter
  • Motor case length 6.8"
  • Ball Bearings
  • Flange Mount (2 screws 6-3/4" apart)
  • 24" wire leads
  • 1 Year mfg warranty

Split Phase Oil Burner Motor. Manual Overload Protection. Continuous Duty; Open Enclosure (Totally Enclosed Non-ventilated when mounted); Class B Insulation; 40C Ambient Temperature; 60 Hertz. S055TBB7618R14B.

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115V
Horsepower 1/6 HP
RPM 1725
Frame 48N
Amperage 3.1 Amps
Bearings Ball Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Reversible
Mounting Flange
Duty Continuous Duty
!
