114167.00 Leeson | 3/4 hp 1725 RPM 56C Frame TEFC C-Face (Rigid Base) Brake Motor 115/208-230V

114167.00 Leeson 3/4 hp 1725 RPM 56C Frame TEFC C-Face (Rigid Base) Brake Motor 115/208-230V

This Leeson brake motor is a 3/4 hp, 1725 RPM, single-phase motor designed for industrial applications requiring reliable braking and precise load control. It replaces Marathon model D402 and is ideal for use in machinery where fail-safe stopping and holding are critical.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1725
• Voltage: 115/208-230V, 60 Hz
• Amperage: 10.8/5.4 A
• Enclosure: TEFC (Totally Enclosed Fan Cooled)
• Frame / Diameter: NEMA 56C Frame
• Shaft Dimensions: Keyed shaft, 5/8" diameter x 1 7/8" length

Product Features & Fitment

This motor features a rigid base with C-face mounting for versatile installation. It includes a fail-safe, spring-set brake manufactured by Stearns, which automatically stops and holds the load when power is turned off. The brake coil operates at 115/230 VAC, 60 Hz, with leads brought into the motor’s conduit box for easy wiring. A power-off manual release is included for convenience and emergency use, resetting automatically after activation.

Cross Reference

• Marathon D402, 056C17F5354

Warranty

1 Year Manufacturer Warranty
