114167.00 Leeson | 3/4 hp 1725 RPM 56C Frame TEFC C-Face (Rigid Base) Brake Motor 115/208-230V

SKU:: 114167
UPC:
Weight:: 40.00 LBS
Width:: 24.00 (in)
Height:: 12.00 (in)
Depth:: 12.00 (in)
Shipping:: Free Shipping
ON SALE:: DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage:: 115/208/230V
Horsepower:: 3/4 HP
RPM:: 1725
Phase:: Single Phase
Frame:: 56C
Enclosure:: TEFC
Hertz:: 60 Hz
Amperage:: 10.8/5.4 Amps
Service Factor:: 1.15
Insulation Class:: Class B
Mounting:: C-Face

Current Stock:

Was: $1,421.40

Now: $1,149.95

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

114167.00 Leeson 3/4 hp 1725 RPM 56C Frame TEFC C-Face (Rigid Base) Brake Motor 115/208-230V

This Leeson brake motor is a 3/4 hp, 1725 RPM, single-phase motor designed for industrial applications requiring reliable braking and precise load control. It replaces Marathon model D402 and is ideal for use in machinery where fail-safe stopping and holding are critical.

Key Specifications

Horsepower: 3/4 hp
RPM: 1725
Voltage: 115/208-230V, 60 Hz
Amperage: 10.8/5.4 A
Enclosure: TEFC (Totally Enclosed Fan Cooled)
Frame / Diameter: NEMA 56C Frame
Shaft Dimensions: Keyed shaft, 5/8" diameter x 1 7/8" length

Product Features & Fitment

This motor features a rigid base with C-face mounting for versatile installation. It includes a fail-safe, spring-set brake manufactured by Stearns, which automatically stops and holds the load when power is turned off. The brake coil operates at 115/230 VAC, 60 Hz, with leads brought into the motor’s conduit box for easy wiring. A power-off manual release is included for convenience and emergency use, resetting automatically after activation.
