N449B Marathon 5 hp 1800 RPM 3-Phase 182TC Frame TEFC (no base) 230/460V Marathon Motor

SKU:
N449B
Weight:
75.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,986.30
Now: $1,805.73
  • 5 hp 1800 RPM, 12.6/6.3 amps 230/460 Volts 60hz. Three Phase
  • NEMA 184TC frame, C-face, Stainless Steel Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • No Base, Reversible, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty, BISSC (Baking Industry Sanitation Standards Committee) Certified

Stainless Steel wash-down motors are use in applications involving challenging caustic environments. This is a three phase electric motor with a C-face mount. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. 184TTWD16032
