GT0077 Marathon 50 hp 1800 RPM 326T Frame 230/460V Open Drip Marathon Electric Motor

GT0077 Marathon 50 hp 1800 RPM 326T Frame 230/460V Open Drip Marathon Electric Motor

This Marathon 50 horsepower, 1800 RPM three-phase electric motor is designed for general-purpose industrial applications. It replaces Leeson models 170021.60, B199714.00, 199714.00 and Dayton 454X67 E601, providing reliable performance in various equipment requiring a NEMA 326T frame motor.

Key Specifications

• Horsepower: 50 hp
• RPM: 1800
• Voltage: 230/460 V
• Amperage: 118.0/59.0 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 326T Frame
• Shaft Dimensions: Keyed shaft, 2 1/8" diameter x 5 1/4" length
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount for stable installation and rolled steel construction for durability. It includes Class F insulation and a service factor of 1.15, though it does not have built-in overload protection. Wiring diagrams are provided on the motor nameplate for ease of connection.

Cross Reference

• Leeson 170021.60, B199714.00, 199714.00; Dayton 454X67 E601

Warranty

1 Year Manufacturer Warranty
