D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor

D2CP2PCR Nidec 2 hp 1800 RPM 56C (No Base) 115/230V ODP 1-Phase Motor

SKU:
D2CP2PCR
Weight:
42.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $941.00
Now: $839.80
Adding to cart… The item has been added
  • 2 hp 1800 RPM, 17.0/8.5 amps 115/230 Volts 60 Hz Cap Start Single Phase Motor
  • NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class B Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor for pumps, conveyors, air compressors, and blowers. Wiring diagram on motor name plate. ODP = Open Drip-Proof. T063CTB2237012B

!
