096002.00 Leeson | Parallel Shaft 1/12 hp, 14 RPM 115/230V Electric Gear Motor

096002.00 Leeson | Parallel Shaft 1/12 hp, 14 RPM 115/230V Electric Gear Motor

SKU:
096002
Availability:
Please email for availability - Currently out of stock at the factory
Weight:
24.00 LBS
Shipping:
Free Shipping
ON SALE:
DISCOUNTED PRICES AND FREE GROUND SHIPPING
Adding to cart… The item has been added
  • 1/12 hp, 14 RPM, 1.3/.65 amps,115/230 Volts 50/60hz.
  • Gear Ratio = 124
  • Torque 330 inch pounds
  • Over Hung Pounds = 459
  • Rotation = Reversible
  • TENV, Keyed Shaft, Ball Bearings

One Year Manufacture Warranty. Features: This worm-type right-angle gearing features hardened, steel worm with bronze worm wheel for long life and quiet operation. Precision machined aluminum housings are used. Gearbox has ball bearings. The housing is sealed and lubrication is permanent with an oil bath. IP55 Washdown Duty. White epoxy paint. Optional L Bracket # M1760011, Optional Conduit Box # 175893.

!
