- 1/3 hp 1200 RPM, 1.6-1.6/0.8 amps 208-230/460 Volts 60 Hz Three Phase Motor
- NEMA 56C frame Keyed Shaft 5/8" Diameter x 1 7/8"
- Service Factor: 1.15, Overload protection = None
- Rigid Base Mount, Ball Bearings, Class B Insulation, Reversible
- 1 Year Manufacture Warranty
General purpose C- Face motor can be used for many applications requiring a three phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. P063ECH3581025B
