U006C Marathon 7.5 hp 1800 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U006C Marathon 7.5 hp 1800 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U006C Marathon 7.5 hp 1800 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U006C Marathon 7.5 hp 1800 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor

Marathon

U006C Marathon 7.5 hp 1800 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor

(No reviews) Write a Review
$1,876.80
$1,490.40
SKU MU006A
UPC 7.23E+11
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 7-1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.6/9.3 Amps
Service Factor 1.15
Insulation Class Class F
Adding to cart… The item has been added
Description
  • 7.5 hp 1800 RPM, 18.6/9.3 amps 230/460 Volts 60hz. Three Phase Motor
  • NEMA 213T Frame Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Explosion Proof: Class 1, Group D; Class II, Group F & G
  • Service Factor: 1.15, Class F Insulation
  • Normally closed thermostats (must be connected to control circuit)
  • Meets temperature code T3B, Shaft slinger
  • TEFC - Explosion Proof Fan cooled
  • 1 Year Manufacture Warranty

Explosion Proof for hazardous locations. Underwrites Laboratories and Canadian Standards Association Listed. Explosion proof conduit box included at no extra cost. 1 year manufacture warranty.

Marathon Model: 213TTGCD6526
Replaces U006B, 213TTGS4026

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 7-1/2 HP
RPM 1800
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.6/9.3 Amps
Service Factor 1.15
Insulation Class Class F
!
