U062C Marathon 7.5 hp 3600 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U062C Marathon 7.5 hp 3600 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U062C Marathon 7.5 hp 3600 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor
U062C Marathon 7.5 hp 3600 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor

Marathon

U062C Marathon 7.5 hp 3600 RPM 213T 230/460V TEFC Explosion Proof Marathon Electric Motor

(No reviews) Write a Review
$1,642.14
$1,440.89
SKU U062C
UPC 7.23E+11
Availability Subject to Availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 230/460V
Horsepower 7-1/2 HP
RPM 3600
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.4/9.2 Amps
Service Factor 1.0
Insulation Class Class F
Adding to cart… The item has been added
Description



  • 7.5 hp 3600 RPM, 18.4/9.2 amps 230/460 Volts 60hz. Three Phase Motor
  • NEMA 213T Frame Keyed Shaft 1 3/8" Diameter x 3 3/8"
  • Explosion Proof: Class 1, Group D; Class II, Group F & G
  • Service Factor: 1.0, Class F Insulation
  • Normally closed thermostats (must be connected to control circuit)
  • Meets temperature code T3B, Shaft slinger
  • TEFC - Explosion Proof Fan cooled
  • 1 Year Manufacture Warranty

This is an updated variant of motors U062B and U062A. Explosion Proof for hazardous locations. Underwrites Laboratories and Canadian Standards Association Listed. Explosion proof conduit box included at no extra cost. 1 year manufacture warranty. 213TTGCD6501

Replaces Leeson 825088.00, Dayton 482P88

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
Voltage 230/460V
Horsepower 7-1/2 HP
RPM 3600
Phase Three Phase
Frame 213T
Enclosure TEFC
Hertz 60 Hz
Amperage 18.4/9.2 Amps
Service Factor 1.0
Insulation Class Class F
!
