1257 Nidec | 0.167 hp 1450 RPM 3-Speed 115-120V; 5" Blower Motor

1257 Nidec | 0.167 hp 1450 RPM 3-Speed 115-120V; 5" Blower Motor

This 0.167 hp blower motor is designed for HVAC applications requiring a reliable, three-speed motor. It serves as a suggested aftermarket replacement for IEC models K48HXTSS-4128, 4128, and K048CLD1123011B, delivering consistent performance in residential and commercial systems.

Key Specifications

• Horsepower: 0.167 hp
• RPM: 1450
• Voltage: 115-120V
• Amperage: 2.5 amps
• Enclosure: Open
• Frame / Diameter: 5" diameter, motor case length 5.2"
• Shaft Dimensions: 8.25" length x 1/2" diameter; shaft height 3 1/2"
• Rotation: CCW (counterclockwise) lead end
• Bearings: Ball bearings

Product Features & Fitment

This motor features a permanent split capacitor design with automatic overload protection and is rated for continuous duty at 40°C ambient temperature. It includes a resilient base mount and comes with a capacitor for easy installation. The motor is equipped with 48" leads to facilitate wiring and connection.

Cross Reference

• IEC K48HXTSS-4128, 4128, K048CLD1123011B

Warranty

1 Year Manufacturer Warranty
