HD3P2E Nidec | 3 hp 1800 RPM 182T Frame 230/460V TEFC Nidec Electric Motor

SKU:: HD3P2E
UPC:
Weight:: 90.00 LBS
Width:: 32.00 (in)
Height:: 20.00 (in)
Depth:: 18.00 (in)
Shipping:: Calculated at Checkout
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 230/460V
Horsepower:: 3 HP
RPM:: 1800
Phase:: Three Phase
Frame:: 182T
Enclosure:: TEFC
Amperage:: 7.8/3.9 Amps
Bearings:: Ball Bearings
Service Factor:: 1.15
Insulation Class:: Class F
Mounting:: Rigid Base
Duty:: Continuous Duty

Current Stock:

Was: $501.40

Now: $369.95

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

HD3P2E Nidec | 3 hp 1800 RPM 182T Frame 230/460V TEFC Nidec Electric Motor

The HD3P2E is a premium efficient, 3 horsepower electric motor designed for industrial applications requiring reliable, continuous duty performance. It replaces model H3P2D and features a rugged cast iron frame suitable for hostile environments such as mills and chemical plants.

Key Specifications

Horsepower: 3 hp
RPM: 1800
Voltage: 230/460 V
Amperage: 7.8/3.9 A
Enclosure: TEFC (Totally Enclosed Fan Cooled)
Frame / Diameter: NEMA 182T
Shaft Dimensions: 1-1/8" diameter x 2-3/4" length (keyed)
Rotation: Reversible
Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount and is designed for continuous duty at ambient temperatures up to 40°C. It includes corrosion-resistant mill and chemical duty paint, a stainless steel nameplate with CE marking, zinc-plated hardware, steel fan cover, conduit box, and condensation drains with plastic plugs. The motor supports variable torque applications up to 20:1 and constant torque up to 5:1 when powered by an inverter. Wiring diagrams are provided on the motor nameplate for easy installation.
