WD3P1ACR Nidec 3 hp 3600 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

WD3P1ACR Nidec 3 hp 3600 RPM 56C Frame (No Base) 208-230/460V TEFC 3-Phase Washdown Motor

SKU:
WD3P1ACR
Weight:
32.00 LBS
Width:
15.00 (in)
Height:
9.00 (in)
Depth:
11.00 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
208/230/460V
Horsepower:
3 HP
RPM:
3600
Phase:
Three Phase
Frame:
56C
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
6.7/3.4 Amps
Bearings:
Ball Bearings
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
C-Face
Was: $955.65
Now: $853.65
Adding to cart… The item has been added
  • 3 hp 3600 RPM, 7.9-6.7/3.4 amps  208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 56C Rolled Steel Frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 Overload protection = None
  • C-Face Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Easy cleaning painted wash-down motor for food and pharmaceutical applications. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. WD3P1ACR

!
