C620V1 Century 1 hp 1800 RPM 1-Phase 56 Frame TEFC (rigid base) 115/208-230V

SKU:
C620V1
Weight:
37.00 LBS
Shipping:
Free Shipping
ON SALE:
PRICE DISCOUNTED AND FREE SHIPPING
Was: $529.70
Now: $499.70
  • 1 hp 1800 RPM, 12.0/6.2-6.0 amps 115/208-230 Volts 60hz. Capacitor Start / Induction Run
  • NEMA 56 frame, Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15, Overload protection = Manual
  • Rigid Base, Reversible, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motors are for use in situations not having special requirements. This is a single phase motor with a rigid base mount. Shaft has keyway. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled.
Replaces Century/AO Smith C620,
