Marathon
C1161 Marathon 2 hp (1 speed) 115/208-230V 3600 RPM ODP 56H Frame Cap Start/Run Resilient Base Motor
(No reviews)
Write a Review
Write a Review
Marathon
C1161 Marathon 2 hp (1 speed) 115/208-230V 3600 RPM ODP 56H Frame Cap Start/Run Resilient Base Motor
$750.26
$645.73
SKU
MC1161
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage
115/208/230V
Horsepower
2 HP
RPM
3600
Frame
56H
Enclosure
ODP
Hertz
60 Hz
Amperage
9.8 Amps
Bearings
Ball Bearings
Speeds
1-Speed
Insulation Class
Class B
- 2 hp 3600 RPM, 19.6/10.4-9.8 amps, 115/208-230 Volts 60 Hz, Capacitor Start, Capacitor Run
- NEMA 56H Frame Keyed Shaft 1 7/8" x 5/8" Diameter, 1 speed
- Service Factor = 1.2, Thermal Protection = Auto
- Resilient Base, Reversible, Ball Bearings, Class B insulation
- 1 Year Manufacture Warranty
Blower motors are used to blow air inside of buildings. Capacitor Start motors have higher starting torque than others. Capacitor Run motors have better efficiency. Shaft may be vertical or horizontal. ODP = Open Drip Proof. 5KCR49RN2148T
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM |
| Voltage | 115/208/230V |
| Horsepower | 2 HP |
| RPM | 3600 |
| Frame | 56H |
| Enclosure | ODP |
| Hertz | 60 Hz |
| Amperage | 9.8 Amps |
| Bearings | Ball Bearings |
| Speeds | 1-Speed |
| Insulation Class | Class B |
